角型电感式接近开关PL-08D1产品介绍

【中文版】
PL-08D1是一款专为工业自动化场景设计的角型电感式接近开关，适用于金属物体的非接触式检测需求。产品采用紧凑的矩形结构设计，结合优化的电磁感应技术，能够在复杂工况中实现稳定可靠的检测功能。

产品优势：

1. 结构设计合理，紧凑的外形便于在有限空间内安装，同时棱角分明的外壳设计增强了对机械应力的耐受性。主体材质选用工程级塑料与金属防护层复合工艺，兼顾轻量化与抗冲击性能。
2. 检测性能经过特殊调校，对铁磁性金属具备良好的检测灵敏度，检测距离经过精密计算，确保在设定范围内保持稳定的检测精度。内置温度补偿电路，可在-25℃至+70℃环境温度范围内维持工作参数稳定。
3. 防护性能优化，对粉尘、油雾及湿度变化具有适应性，特殊密封处理使产品能够应对轻度腐蚀性环境。采用全封闭式结构设计，有效防止外部颗粒物侵入内部电路。
4. 支持多种安装方式，提供侧面或端面固定选择，配备标准尺寸安装孔位，便于集成到各类自动化设备中。输出接线采用耐弯折线缆，端子连接方式简化现场布线流程。

技术参数：
检测物体：铁系金属（建议检测物尺寸≥8mm）
检测距离：最大4mm（视材质而定）
电源电压：DC 10-30V
输出类型：NPN/PNP可选
响应频率：200Hz
壳体材质：增强型PBT+不锈钢部件
防护等级：IP67
工作温度：-25℃～+70℃

应用场景广泛应用于自动化生产线定位检测、机床刀具到位确认、输送带金属部件计数、包装机械位置控制等场景。典型应用包括注塑机模组定位、机械臂末端工具识别、立体仓库货物感应等需要精准检测金属物体位置的工业环境。

该产品经过严格的生产工艺控制与多重质量检测程序，致力于为工业自动化系统提供可靠的检测解决方案。我们持续关注产品在实际应用中的表现，通过不断优化内部电路设计与机械结构，提升产品在复杂工况下的适应能力。

【English Version】
The PL-08D1 rectangular inductive proximity switch is engineered for non-contact detection of metallic objects in industrial automation systems. Featuring a compact angular housing design, this device integrates enhanced electromagnetic sensing technology to deliver consistent performance in demanding operational environments.

Product Highlights:

1. The space-saving rectangular configuration allows flexible installation in constrained spaces. The reinforced housing combines engineering-grade polymers with metal shielding, achieving an optimal balance between impact resistance and lightweight construction.
2. Precision-tuned detection characteristics ensure reliable sensing of ferrous metals within specified ranges. Integrated temperature compensation circuitry maintains operational stability across a broad temperature spectrum from -25℃ to +70℃.
3. Enhanced environmental protection design features multi-layer sealing technology, providing effective resistance against dust ingress, oil mist exposure, and humidity variations. The fully enclosed structure safeguards internal components from particulate contamination.
4. Versatile mounting options include side or end fixation configurations, with standardized mounting holes for seamless integration into automation equipment. Durable flexible cabling with reinforced strain relief ensures long-term wiring reliability.

Technical Specifications:
Target Material: Ferrous metals (recommended target size ≥8mm)
Sensing Distance: Max.4mm (material dependent)
Supply Voltage: DC 10-30V
Output Configuration: Selectable NPN/PNP
Switching Frequency: 200Hz
Housing Material: Reinforced PBT with stainless steel components
Ingress Protection: IP67
Operating Temperature: -25℃～+70℃

Typical applications encompass position verification in CNC machining centers, metal part counting on conveyor systems, tool presence detection in robotic assemblies, and material handling equipment positioning. Common implementations include injection molding machine component tracking, automated warehouse pallet detection, and production line fixture alignment monitoring.

Manufactured with stringent process controls and multi-stage quality verification, this proximity switch demonstrates consistent performance in diverse industrial settings. Continuous product optimization focuses on improving circuit reliability and mechanical durability to meet evolving automation requirements.
