角型电感式接近开关NI15-Q30-AP6X 厂家
产品概述
角型电感式接近开关NI15-Q30-AP6X是一款专为工业自动化控制设计的高性能检测装置，采用先进的电磁感应原理实现非接触式金属物体检测。产品外形采用30mm×30mm的方形结构，便于在有限空间内安装，适合各类机械设备和生产线的位置检测需求。该开关具有坚固耐用的ABS外壳，能够在-25℃至+70℃的宽温度范围内稳定工作，防护等级达到IP67，可有效抵御粉尘、油污和水溅等恶劣环境因素的影响。613
技术特点
该产品采用直流三线制接线方式，工作电压范围为10-30VDC，输出电流可达200mA，支持NPN/PNP两种输出模式，用户可根据实际需求选择常开或常闭型配置。感应距离为15mm，响应频率高达400Hz，能够快速准确地检测磁性金属物体的接近状态。独特的角型设计使得感应面可以灵活调整方向，适应不同角度的安装要求，同时优化的电路设计确保了在强电磁干扰环境下的可靠工作性能。1528
应用领域
角型电感式接近开关NI15-Q30-AP6X广泛应用于自动化生产线、包装机械、数控机床、物流输送系统等工业场景。在机床行业中，可用于刀具位置检测和工作台限位控制；在流水线系统中，可实现产品计数和位置定位；在仓储设备中，可检测货物到位情况。其稳定可靠的性能特别适合需要长期连续运行的工况，如汽车制造、食品加工和电子组装等行业。1319
Product Overview
The rectangular inductive proximity switch NI15-Q30-AP6X is a high-performance sensing device designed for industrial automation control, utilizing electromagnetic induction principle for non-contact detection of metal objects. Featuring a compact 30mm×30mm square housing, it enables easy installation in confined spaces and meets various positioning detection requirements in machinery and production lines. The durable ABS housing ensures reliable operation within a wide temperature range from -25℃ to +70℃, with IP67 protection against dust, oil and water splash. 613
Technical Features
This product adopts 3-wire DC connection with operating voltage range of 10-30VDC and output current up to 200mA, supporting both NPN and PNP configurations with optional normally open or normally closed modes. The sensing distance reaches 15mm with fast response frequency of 400Hz, enabling precise detection of approaching ferrous metal objects. The unique angular design allows flexible adjustment of sensing surface direction to accommodate various installation angles, while optimized circuit design ensures stable performance even in strong electromagnetic interference environments. 1528
Application Fields
The rectangular inductive proximity switch NI15-Q30-AP6X is widely used in industrial applications including automated production lines, packaging machinery, CNC equipment and logistics conveying systems. In machine tool industry, it can detect tool position and worktable limit; in assembly lines, it enables product counting and positioning; in warehouse equipment, it monitors cargo presence. Its stable performance makes it particularly suitable for long-term continuous operation in automotive manufacturing, food processing and electronic assembly industries. 1319
角型电感式接近开关
PS17-5D1, PS17-5D2, PS17-5Y1, PS17-5Y2, PS-05N, PS-05N2, PS-05N3, PS-05P, PS-05P2 PS-05P3, PS-05D1, PS-05D2, PS-05Y1, PS-05Y2,PL-05N, PL-05N2, PL-05N3, PL-05P, PL-05P2, PL-05P3, PL-05D1, PL-05D2, PL-05Y1, PL-05Y2,PL-08N, PL-08N2 PL-08N3, PL-08P, PL-08P2, PL-08P3, PL-08D1, PL-08D2, PL-08Y1,PL-08Y2,SN04-N1 SN04-N2,SN04-N3,SN04-P,SN04-P2,SN04-P3,SN04-D1,SN04-D2,SN04-Y1,SN04-Y2,SN05-N1 SN05-N2, SN05-N3, SN05-P, SN05-P2, SN05-P3, SN05-D1, SN05-D2, SN05Y1, SN05-Y2,
SN06-N1, SN06-N2, SN06-N3, SN06-P, SN06-P2, SN06-P3, SN06-D1, SN06-D2, SN06-Y1 SN06-Y2, SN07-N, SN07-N2, SN07-N3, SN07-P, SN07-P2, SN07-P3, SN07-D1, SN07-D2 SN07Y1, SN07-Y2,NI10-Q25-AN6X, NI10-Q25-RN6X, NI10-Q25-RP6X, NI10- Q25-AP6X
NI10-Q25-AD4X, NI10-Q25-RD4X, NI10-Q25-AZ3X, NI10-Q25-RZ3X,NI15-Q30-AN6X NI15-Q30-RN6X, NI15-Q30-RP6X, NI15-Q30-AP6X, NI15-Q30-AD4X, NI15-Q30-RD4X NI15-Q30-AZ3X, NI15-Q30-RZ3X,
接近开关，磁性开关,被广泛应用于各种机械、机床制造业及纺织、造纸、烟草、轻工、食品、化工、矿山、冶金、航空工业、电力保安、汽车工业、船舶交通运输、建筑、地等各行各业，作限位、定位检测，自动计数，测速，自动保护，工业生产自动流水线及微机信号，数控装置等应用.详细技术资料请到公司网站查询 .FJ13-25KA
FJ13 安装方式埋入式非埋入式检测距离 25mm 交流AC90-250V二线制NO 常开 FJ13-M25KA NC 常闭 FJ13-M25KB 三线制NO+NC 常开常闭 FJ13-M25KE 继电输出四线NO+NC 常开常闭 FJ13-M25JC 继电输出五线NO+NC 常开常闭 直流DC6-36VNPNNO 常开 FJ13-M25NA NC 常闭 FJ13-M25NB NO+NC 常开常闭 FJ13-M25NC PNPNO 常开 FJ13-M25PA NC 常闭 FJ13-M25PB NO+NC 常开常闭 FJ13-M25PC 二线制NO 常开 FJ13-M25LA NC 常闭 FJ13-M25LB 输出电压降DC/ACAC 输出电流可控硅SCR 300mA 继电器1A、2A DC三线200mA DC二线 50mA重复精度 消耗电流 响应频率DC 300Hz,AC 10Hz 外壳体材料塑料ABS设定距离0-20mm 标准检测物体60 x 60 x 1（铁）工作环境温度-20℃~+55℃连接方式1.5m PVC电缆防护等级IP67
|
