铠装铂电阻WZPK-565U 厂家
中文介绍
WZPK-565U铠装铂电阻是一种高性能的温度传感器，广泛应用于工业测温领域。该产品采用薄膜铂电阻测温元件，具备精确、灵敏、热响应时间快、质量稳定、使用寿命长等优点。其外保护管采用不锈钢材质，内部填充高密度氧化镁绝缘体，具有很强的抗污染能力和优良的机械强度，能够在恶劣环境下稳定工作。
WZPK-565U的直径较小且易于弯曲，适合安装在装配式铂电阻无法安装的场合。其测温范围为-200℃至+850℃，能够满足多种工业场景的温度测量需求。此外，该产品还具备良好的电输出性能，可为显示仪、记录仪、调节仪、扫描仪及电脑等设备提供精确的输入值。
English Introduction
The WZPK-565U armored platinum resistance thermometer is a high-performance temperature sensor widely used in industrial temperature measurement. This product uses a thin-film platinum resistance temperature element, which offers high precision, sensitivity, fast thermal response time, stable quality, and a long service life. The outer protective tube is made of stainless steel and filled with high-density magnesium oxide insulator, providing strong anti-pollution capability and excellent mechanical strength, making it suitable for harsh working environments.
With a small diameter and high flexibility, the WZPK-565U can be easily installed in places where conventional platinum resistance thermometers cannot be installed. Its temperature measurement range is from -200°C to +850°C, meeting the temperature measurement needs of various industrial scenarios. Additionally, the product has good electrical output performance and can provide precise input values for instruments such as display meters, recorders, regulators, scanners, and computers.
铠装铂电阻
WZPK-563U，WZPK-564U，WZPK-565U，WZPK-566U，WZPK-173U，WZPK-174U，WZPK-175U，WZPK-176U，WZPK-273U，WZPK-274U，WZPK-275U，WZPK-276U，WZPK-373U，WZPK-374U，WZPK-375U，WZPK-376U，WZPK-473U，WZPK-474U，WZPK-475U，WZPK-476U，WZPK-573U，WZPK-574U，WZPK-575U，WZPK-576U，WZPK-103S，WZPK-104S，WZPK-105S，WZPK-106S，WZPK2-105SA，WZPK2-106SA，WZPK-203S，WZPK-204S，WZPK-205S，WZPK-206S，WZPK2-205SA，WZPK2-206SA，WZPK-303S，铠装铂电阻，WZPK-535S，WZPK-533S，WZPK-534S，WZPK2-436SA，WZPK2-435SA，WZPK-435S，WZPK-434S，WZPK-433S，WZPK2-336SA，WZPK-235U，WZPK-134U，WZPK-236S，WZPK2-335SA，WZPK-336S，WZPK-235S，WZPK-325U，WZPK-234S，WZPK-335S，WZPK-404U，WZPK-126U，WZPK-334S，WZPK-233S，WZPK-365U，WZPK2-136SA，WZPK-333S，WZPK2-236SA，WZPK2-135SA，WZPK-136S，WZPK2-235SA，WZPK-135S，WZPK-134S，WZPK-524U，WZPK-123U，WZPK2-525SA，WZPK-525S，WZPK-524S，WZPK-523S，WZPK2-425SA，WZPK-425S，WZPK-424S，WZP2-44SAB，WZPK-423S，WZPK-326S，WZPK2-325SA，WZPK-325S，WZPK-323S，WZPK-324S，WZPK2-226SA，WZPK2-225SA，WZPK-226S，WZPK-225S，WZPK-223S，WZPK2-126SA，WZPK2-125SA，WZPK-125S，WZPK-126S，WZPK-124S，WZPK-123S，WZPK2-506SA，WZPK2-505SA，WZP2-420D，
概述
铠装铂电阻是一种温度传感器，它比装配式铂电阻直径小，易弯曲，抗震性好，适宜安装在装配式铂电阻无法安装的场合。本公司生产的WZPK系列铠装铂电阻采用引进铂电阻测温元件，因此，具有精确、灵敏、热响应时间快、质量稳定、使用寿命长等特点。
特点
★ 热响应时间短，减小动态误差
★ 直径小，长度不受限制
★ 测量精确度高
★ 进口薄膜电阻元件，性能可靠稳定
工作原理
铠装铂电阻是利用物质在温度变化时，其电阻值也随着发生变化的特征来测量温度的，当阻值变
化时，工作仪表便显示出阻值所对应的温度值。
|
