铠装铂电阻WZP2-44SAB 供应
产品概述
铠装铂电阻WZP2-44SAB是一款专为工业环境设计的精密温度传感器，采用特殊防爆结构设计，适用于存在爆炸性气体环境的场所。该产品比传统装配式铂电阻直径更小且柔韧性优异，能轻松适应管道狭窄或空间受限的安装场景。产品核心采用高品质铂电阻测温元件，配合不锈钢铠装保护管与高密度氧化绝缘材料，确保在-200℃至500℃范围内实现快速响应和高精度测量，特别适合化工、石油、能源等领域的温度监控需求。1429
核心技术特点
WZP2-44SAB铠装铂电阻通过整体拉伸工艺制造，结构抗震性强，彻底避免外护管断裂风险。其铠装层采用不锈钢材质，内部填充高密度氧化镁绝缘体，兼具抗腐蚀性与机械强度，可长期稳定工作在粉尘、潮湿等恶劣环境。热响应时间根据直径不同控制在3-12秒，显著减少动态误差；直径选择范围为φ3-φ6mm，长度支持定制化需求，满足多样化安装条件。内置进口薄膜电阻元件，温度测量精度达到±(0.15+0.002|t|)℃级别，性能稳定可靠。71522
应用场景
本产品广泛适用于各类工业过程控制场景，包括反应釜温度监测、管道流体温度检测、机械设备表面温度测量等。通过与显示仪表、记录仪、PLC系统或计算机直接连接，可实时提供精准的温度信号，为生产自动化控制提供关键数据支持。独特的防爆设计使其成为化工厂、炼油厂、天然气站等危险区域的安全选择，能有效预防因温度监测失效引发的安全事故。21121
产品优势
铠装铂电阻WZP2-44SAB采用模块化设计，提供固定螺纹、法兰等多种安装方式，适配不同现场需求。优化的结构设计使其在保持小型化特点的同时，仍具备优异的抗振动和抗冲击性能。产品接线盒采用高强度铝合金铸造，配合特殊密封工艺，确保电气安全与长期密封性。铜导线直连设计简化了二次仪表接入流程，用户可便捷地获取线性良好的电阻-温度特性输出。51325
Armoured Platinum Resistance WZP2-44SAB
The WZP2-44SAB is a professionally engineered temperature sensor featuring compact armoured construction with superior flexibility. Its stainless-steel sheath contains high-purity platinum sensing elements and magnesium oxide insulation, delivering reliable performance across -200°C to 500°C with rapid thermal response. The unique armour design provides exceptional resistance to vibration, corrosion and mechanical stress, making it ideal for confined spaces or harsh industrial environments. 1623
Key Performance Features
This sensor distinguishes itself through precision-engineered platinum thin-film elements that ensure measurement consistency within ±(0.15+0.002|t|)℃ tolerance. Available in diameters from 3mm to 6mm with customizable lengths, it accommodates diverse installation requirements. The robust armour construction maintains signal integrity even under continuous vibration, while the oxidation-resistant materials guarantee long-term stability in chemically aggressive media. Response times as fast as 3 seconds minimize process control lag. 71220
Typical Applications
Extensively implemented in petrochemical plants, power generation facilities and manufacturing processes, this sensor provides critical temperature data for reactors, pipelines, heat exchangers and rotating equipment. Its explosion-proof characteristics make it particularly valuable for monitoring flammable gas/liquid temperatures in refineries and chemical processing units. When integrated with control systems, it enables real-time temperature regulation and safety interlocking. 3927
Installation Benefits
The WZP2-44SAB offers versatile mounting options including threaded and flanged connections, facilitating retrofit or new installations. The hermetically sealed junction box with corrosion-resistant alloys prevents moisture ingress, while the straightforward wiring configuration simplifies field commissioning. Engineered for maintenance-free operation, this sensor reduces downtime while providing consistent measurement accuracy throughout its service life. 4824
铠装铂电阻
WZPK-563U，WZPK-564U，WZPK-565U，WZPK-566U，WZPK-173U，WZPK-174U，WZPK-175U，WZPK-176U，WZPK-273U，WZPK-274U，WZPK-275U，WZPK-276U，WZPK-373U，WZPK-374U，WZPK-375U，WZPK-376U，WZPK-473U，WZPK-474U，WZPK-475U，WZPK-476U，WZPK-573U，WZPK-574U，WZPK-575U，WZPK-576U，WZPK-103S，WZPK-104S，WZPK-105S，WZPK-106S，WZPK2-105SA，WZPK2-106SA，WZPK-203S，WZPK-204S，WZPK-205S，WZPK-206S，WZPK2-205SA，WZPK2-206SA，WZPK-303S，铠装铂电阻，WZPK-535S，WZPK-533S，WZPK-534S，WZPK2-436SA，WZPK2-435SA，WZPK-435S，WZPK-434S，WZPK-433S，WZPK2-336SA，WZPK-235U，WZPK-134U，WZPK-236S，WZPK2-335SA，WZPK-336S，WZPK-235S，WZPK-325U，WZPK-234S，WZPK-335S，WZPK-404U，WZPK-126U，WZPK-334S，WZPK-233S，WZPK-365U，WZPK2-136SA，WZPK-333S，WZPK2-236SA，WZPK2-135SA，WZPK-136S，WZPK2-235SA，WZPK-135S，WZPK-134S，WZPK-524U，WZPK-123U，WZPK2-525SA，WZPK-525S，WZPK-524S，WZPK-523S，WZPK2-425SA，WZPK-425S，WZPK-424S，WZP2-44SAB，WZPK-423S，WZPK-326S，WZPK2-325SA，WZPK-325S，WZPK-323S，WZPK-324S，WZPK2-226SA，WZPK2-225SA，WZPK-226S，WZPK-225S，WZPK-223S，WZPK2-126SA，WZPK2-125SA，WZPK-125S，WZPK-126S，WZPK-124S，WZPK-123S，WZPK2-506SA，WZPK2-505SA，WZP2-420D，
概述
铠装铂电阻是一种温度传感器，它比装配式铂电阻直径小，易弯曲，抗震性好，适宜安装在装配式铂电阻无法安装的场合。本公司生产的WZPK系列铠装铂电阻采用引进铂电阻测温元件，因此，具有精确、灵敏、热响应时间快、质量稳定、使用寿命长等特点。
特点
★ 热响应时间短，减小动态误差
★ 直径小，长度不受限制
★ 测量精确度高
★ 进口薄膜电阻元件，性能可靠稳定
工作原理
铠装铂电阻是利用物质在温度变化时，其电阻值也随着发生变化的特征来测量温度的，当阻值变
化时，工作仪表便显示出阻值所对应的温度值。
|
