电接点双金属温度计WZPK-364S产品介绍（中英双语）
【中文版】
产品概述：
WZPK-364S型电接点双金属温度计是一款专为工业过程温度监测与控制设计的机械式仪表，采用双金属传感原理与电接点信号输出相结合的创新结构。其核心组件通过精密加工的双金属片热感应元件，将温度变化转化为机械位移，同步驱动指针指示温度数值，并通过可调节接点装置实现预设温度点的开关信号输出，满足自动化系统的联动控制需求。
核心优势：
- 宽域适用性：支持-40℃至500℃的宽温度测量范围，适配多种工业场景需求；
- 双重功能集成：兼具现场直观指示与远程信号传输能力，实现监测与控制一体化；
- 稳定结构设计：全密闭不锈钢外壳配合抗震表盘结构，耐受振动、粉尘及潮湿环境；
- 灵活配置方案：提供轴向/径向多种表头安装方向，接点数量可定制为单上限、下限或上下限组合；
- 便捷维护特性：表壳配备密封填料函结构，支持现场快速更换感温元件。
典型应用：
本产品广泛应用于石油化工设备温度保护、电力机组冷却系统监控、食品加工灭菌温度跟踪、暖通空调机组启停控制等场景。其机械式设计无需外部供电的特性，特别适用于防爆要求区域及野外作业环境。
技术参数：
• 精度等级：符合行业通用1.5级精度
• 接点容量：AC 220V/1A（阻性负载）
• 防护性能：IP54防护等级壳体
• 探杆规格：标配Φ6mm不锈钢探杆，插入长度可定制
• 环境适应性：-10℃~55℃环境温度正常运作
服务支持：
我们提供完善的技术咨询、选型指导和售后维护服务，可根据客户现场工况推荐适配的安装附件及防护配件，协助实现最优系统集成方案。
【English Version】
Product Overview:
The WZPK-364S Bimetallic Temperature Gauge with Electrical Contact is a mechanical instrument designed for industrial temperature monitoring and control. Integrating bimetallic sensing technology with electrical contact output, its precision-engineered bimetallic strip converts thermal expansion into mechanical displacement, driving both analog pointer indication and preset contact switching for automated system integration.
Key Features:
- Extended Measurement Range: Covers -40℃ to 500℃ for diverse industrial applications
- Dual Functionality: Combines local visual reading with remote electrical signaling
- Robust Construction: Stainless steel housing with anti-vibration design ensures reliability in harsh conditions
- Customizable Configuration: Axial/radial mounting options and adjustable contact settings (SPDT/DPDT)
- Maintenance-friendly Design: Sealed gland assembly enables in-field sensor replacement
Typical Applications:
Ideal for process temperature monitoring in petrochemical plants, HVAC system control, food processing sterilization verification, and power generation equipment protection. Particularly suited for hazardous areas requiring intrinsic safety.
Technical Specifications:
• Accuracy: Industry-standard Class 1.5
• Contact Rating: 1A @ 220V AC (resistive load)
• Housing Protection: IP54 certified enclosure
• Stem Configuration: Standard 6mm stainless steel probe with customizable immersion lengths
• Ambient Tolerance: Operational in -10℃~55℃ environments
Service Commitment:
Our engineering team provides comprehensive technical consultation, customized selection guidance, and responsive after-sales support. Tailored installation accessories and protective fittings are available to optimize system integration for specific operational requirements.
