‌油雾器过滤器产品说明（中文）‌
本系列油雾器过滤器专为工业润滑系统及气动设备中的油雾分离需求设计，通过对气流中悬浮油雾颗粒的高效捕捉，有效保障设备运行洁净度与稳定性。产品采用模块化结构，适配多种工况场景，在确保核心功能优化的同时，兼顾安装便捷性与长期维护成本控制。

‌核心运行参数‌

• 过滤精度范围：0.3~5微米（分级可选）
• 额定处理流量：20~800 m³/h（多规格覆盖）
• 工作压力区间：0.2~1.6 MPa
• 壳体材质：抗腐蚀铝合金/不锈钢双版本
• 适用温度：-20℃至120℃
• 接口规格：1/4"~2"标准管螺纹或法兰连接

‌技术特性说明‌
多层复合滤芯结构通过梯度拦截原理实现油雾分离效率提升，首层金属烧结网预过滤大颗粒杂质，中间层超细玻璃纤维吸附微小油雾，末级疏油涂层防止二次滴漏。导流腔体经流体动力学仿真优化，压损控制在＜200Pa@额定流量，相较传统结构节能15%以上。快拆式滤芯模块支持无工具更换，维护周期可根据实际工况通过透明视窗观测灵活调整。

‌典型应用场景‌
适用于数控机床切削油雾回收、螺杆空压机排气净化、注塑机液压站环境治理等场景，可有效缓解车间空气污染、降低设备因油污积聚导致的故障率。特殊防爆结构设计版本可满足喷涂车间、粉尘作业区等环境的安全要求。

‌使用效益要点‌
通过精密的多级过滤机制，设备出口气体含油量可降至5ppm以下，显著延长后端精密元件使用寿命。主体结构经过表面硬化处理与气密性检测，在振动、温变等复杂工况下仍保持稳定性能。建议定期检查集油槽液位并按需清理，可保持设备持续高效运行。

‌Oil Mist Filter Product Description (English)‌
This series of oil mist filters is engineered for industrial lubrication systems and pneumatic equipment, providing efficient separation of suspended oil aerosol particles from airflow to ensure operational cleanliness and system reliability. Featuring modular design, the product adapts to diverse working conditions while balancing installation flexibility with long-term maintenance efficiency.

‌Key Operational Parameters‌

• Filtration precision: 0.3~5μm (graded options)
• Flow capacity: 20~800 m³/h (multi-configuration)
• Operating pressure: 0.2~1.6 MPa
• Housing material: Corrosion-resistant aluminum alloy/stainless steel
• Temperature range: -20℃ to 120℃
• Connection ports: 1/4"~2" pipe threads or flanges

‌Technical Highlights‌
The multi-stage composite filter cartridge adopts gradient interception technology, where the primary sintered metal layer captures large particulates, the intermediate glass microfiber layer traps submicron oil mist, and the terminal hydrophobic coating prevents residual dripping. The optimized flow channel design, validated by CFD simulation, maintains pressure drop below 200Pa@rated flow, achieving over 15% energy savings compared to conventional models. Tool-free cartridge replacement and transparent observation window enable proactive maintenance scheduling.

‌Typical Applications‌
Ideal for CNC machine tool mist recovery, screw compressor exhaust treatment, and hydraulic station emission control in injection molding systems. Explosion-proof variants meet safety requirements in spray booths and combustible dust environments.

‌Operational Advantages‌
Post-filtration oil content at outlet remains below 5ppm, effectively protecting downstream components from contamination. The hardened housing structure with pressure-tested sealing ensures consistent performance under vibration and thermal cycling. Routine inspection of condensate collection chambers and timely drainage are recommended for sustained efficiency.
