角型电感式接近开关SN04-D1 价格
产品概述
SN04-D1角型电感式接近开关是一款采用非接触式检测技术的工业级传感器，专为金属物体检测设计。该产品具有方形外观结构，尺寸紧凑（181835mm），适合在空间受限的安装环境中使用。其核心采用电磁感应原理，能够稳定检测铁、钢、铜等导电金属材料，检测距离为4mm±10%，响应频率高达800Hz，可满足高速自动化生产线的需求。产品外壳采用PBT工程塑料，具备IP67防护等级，能适应-25℃至70℃的工作环境，在粉尘、油污等工业场景中表现可靠。1822
技术特点
该开关提供多种接线方式（NPN/PNP常开/常闭），支持DC10-30V宽电压输入，内置浪涌保护、逆极性保护和短路保护功能。独特的设计使其具备抗电磁干扰能力，残留电压≤2.5V，消耗电流≤10mA，负载电流可达200mA。产品采用埋入式/非埋入式两种安装方式，通过黄色LED指示灯直观显示工作状态。特别优化的电路设计使开关具备≤3%的重复误差和1-20%的迟滞范围，确保在连续作业中保持稳定的检测精度。电缆标配2米PVC护套线，便于现场布线安装。2327
应用场景
SN04-D1广泛应用于机械制造、纺织设备、包装机械等领域的定位检测、计数控制和安全防护。在自动化生产线中，可用于检测传送带上的金属工件、监控机械臂末端位置；在数控机床上，可实现刀具极限位置保护；在物流分拣系统里，能准确识别金属托盘。其非接触式工作原理避免了传统机械开关的磨损问题，特别适用于高频次、高精度的工业自动化场景。产品还可与PLC、变频器、伺服控制器等设备直接配合使用，构建完整的控制系统。921
Product Introduction
The SN04-D1 rectangular inductive proximity switch is an industrial-grade sensor designed for non-contact detection of metallic objects. Featuring a compact square housing (181835mm), it employs electromagnetic induction technology to reliably detect ferrous and non-ferrous metals with a sensing range of 4mm±10%. The switch operates at a high response frequency of 800Hz, making it suitable for high-speed automation applications. Its PBT plastic enclosure provides IP67 protection against dust and moisture, with an operational temperature range from -25°C to 70°C. The product offers multiple output configurations including NPN/PNP NO/NC models. 1824
Key Features
This proximity sensor supports 10-30VDC wide voltage input and incorporates built-in protection against reverse polarity, surge currents, and short circuits. With ≤3% repeat accuracy and 1-20% hysteresis, it ensures consistent performance in demanding environments. The device features a yellow status LED, ≤2.5V residual voltage, and ≤10mA current consumption while delivering up to 200mA load capacity. Standard models include 2-meter PVC cables for easy installation, available in flush or non-flush mounting styles. The optimized electromagnetic design provides excellent noise immunity for stable operation near motors or frequency converters. 2228
Typical Applications
Ideal for industrial automation systems, the SN04-D1 excels in position sensing, object counting, and safety interlocking applications. Common uses include metal workpiece detection on conveyor lines, end-of-arm tooling positioning in robotics, and pallet recognition in logistics sorting systems. Its wear-free operation makes it particularly suitable for high-cycle applications like CNC machine tool limit protection, packaging equipment synchronization, and textile machinery control. The sensor can interface directly with PLCs, servo drives, and other control devices to form complete monitoring solutions. 721
角型电感式接近开关
PS17-5D1, PS17-5D2, PS17-5Y1, PS17-5Y2, PS-05N, PS-05N2, PS-05N3, PS-05P, PS-05P2 PS-05P3, PS-05D1, PS-05D2, PS-05Y1, PS-05Y2,PL-05N, PL-05N2, PL-05N3, PL-05P, PL-05P2, PL-05P3, PL-05D1, PL-05D2, PL-05Y1, PL-05Y2,PL-08N, PL-08N2 PL-08N3, PL-08P, PL-08P2, PL-08P3, PL-08D1, PL-08D2, PL-08Y1,PL-08Y2,SN04-N1 SN04-N2,SN04-N3,SN04-P,SN04-P2,SN04-P3,SN04-D1,SN04-D2,SN04-Y1,SN04-Y2,SN05-N1 SN05-N2, SN05-N3, SN05-P, SN05-P2, SN05-P3, SN05-D1, SN05-D2, SN05Y1, SN05-Y2,
SN06-N1, SN06-N2, SN06-N3, SN06-P, SN06-P2, SN06-P3, SN06-D1, SN06-D2, SN06-Y1 SN06-Y2, SN07-N, SN07-N2, SN07-N3, SN07-P, SN07-P2, SN07-P3, SN07-D1, SN07-D2 SN07Y1, SN07-Y2,NI10-Q25-AN6X, NI10-Q25-RN6X, NI10-Q25-RP6X, NI10- Q25-AP6X
NI10-Q25-AD4X, NI10-Q25-RD4X, NI10-Q25-AZ3X, NI10-Q25-RZ3X,NI15-Q30-AN6X NI15-Q30-RN6X, NI15-Q30-RP6X, NI15-Q30-AP6X, NI15-Q30-AD4X, NI15-Q30-RD4X NI15-Q30-AZ3X, NI15-Q30-RZ3X,
接近开关，磁性开关,被广泛应用于各种机械、机床制造业及纺织、造纸、烟草、轻工、食品、化工、矿山、冶金、航空工业、电力保安、汽车工业、船舶交通运输、建筑、地等各行各业，作限位、定位检测，自动计数，测速，自动保护，工业生产自动流水线及微机信号，数控装置等应用.详细技术资料请到公司网站查询 .FJ13-25KA
FJ13 安装方式埋入式非埋入式检测距离 25mm 交流AC90-250V二线制NO 常开 FJ13-M25KA NC 常闭 FJ13-M25KB 三线制NO+NC 常开常闭 FJ13-M25KE 继电输出四线NO+NC 常开常闭 FJ13-M25JC 继电输出五线NO+NC 常开常闭 直流DC6-36VNPNNO 常开 FJ13-M25NA NC 常闭 FJ13-M25NB NO+NC 常开常闭 FJ13-M25NC PNPNO 常开 FJ13-M25PA NC 常闭 FJ13-M25PB NO+NC 常开常闭 FJ13-M25PC 二线制NO 常开 FJ13-M25LA NC 常闭 FJ13-M25LB 输出电压降DC/ACAC 输出电流可控硅SCR 300mA 继电器1A、2A DC三线200mA DC二线 50mA重复精度 消耗电流 响应频率DC 300Hz,AC 10Hz 外壳体材料塑料ABS设定距离0-20mm 标准检测物体60 x 60 x 1（铁）工作环境温度-20℃~+55℃连接方式1.5m PVC电缆防护等级IP67
|
