角型电感式接近开关SN05-N3 供应
产品概述
角型电感式接近开关SN05-N3是一款基于电磁感应原理设计的高性能非接触式检测装置，专为工业自动化场景中的金属物体位置检测而开发。其采用紧凑的方形结构设计，便于安装与集成，适用于机械加工、物流分拣、设备安全防护等多种领域。该产品通过感应金属物体靠近时产生的涡流变化实现快速响应，确保检测过程稳定可靠。
SN05-N3具备优异的抗干扰能力和环境适应性，可在复杂工况下保持精准检测。其内部采用优化的振荡电路和信号处理技术，有效提升动作一致性，避免误触发。产品提供三线制接线方式（NPN/PNP可选），支持常开或常闭输出模式，兼容主流PLC及控制系统的信号输入需求。感应距离可达5mm，响应频率为500Hz，满足高速检测场景的要求。
英文介绍（Overview）
The angular inductive proximity switch SN05-N3 is a high-performance non-contact detection device based on electromagnetic induction, designed for position sensing of metallic objects in industrial automation. Its compact rectangular housing facilitates easy installation and integration, making it suitable for applications such as machining, logistics sorting, and equipment safety protection.
By detecting eddy current changes generated when metal targets approach, the SN05-N3 ensures rapid response and stable operation. The product features enhanced anti-interference capabilities and environmental durability, maintaining accuracy even in challenging conditions. With an optimized oscillation circuit and signal processing technology, it delivers consistent actuation without false triggering.
The switch adopts a 3-wire connection (NPN/PNP configurable) and supports both normally open (NO) and normally closed (NC) output modes, compatible with most PLCs and control systems. Its sensing range reaches 5mm, and a response frequency of 500Hz meets high-speed detection requirements.
技术特点
SN05-N3采用全封闭式结构，外壳材质坚固耐腐蚀，防护等级达IP67，可抵御粉尘、油污及短时水浸影响。其工作电压范围覆盖DC 10-30V，电压波动容忍度达±15%，适应工业现场不稳定的电源环境。产品通过精密调校的感应线圈设计，确保对铁、铝、铜等多种金属材质均具有稳定的检测性能。
英文介绍（Features）
The SN05-N3 features a fully enclosed housing with robust and corrosion-resistant materials, achieving IP67 protection against dust, oil, and temporary water immersion. It operates within a wide voltage range of DC 10-30V, tolerating fluctuations up to ±15% to suit unstable power supply environments.
The precision-tuned sensing coil ensures stable detection performance for various metals including iron, aluminum, and copper. Its temperature stability allows operation in environments ranging from -25°C to +70°C, ensuring reliability in extreme conditions.
应用场景
该产品适用于自动化产线中的工件到位检测、设备安全门状态监控、流水线计数等场景。其非接触式设计避免了机械磨损，显著延长使用寿命。在包装机械、汽车装配、电子制造等领域，SN05-N3可精准触发控制信号，提升生产效率和安全性。
英文介绍（Applications）
Ideal for automated production lines, the SN05-N3 is widely used in workpiece presence detection, safety door monitoring, and conveyor counting. Its non-contact design eliminates mechanical wear, significantly extending service life.
In packaging machinery, automotive assembly, and electronics manufacturing, the switch provides precise signal triggering to enhance productivity and operational safety. The compact size and versatile mounting options further simplify integration into space-constrained installations.
注：以上介绍避免使用极限化表述，聚焦产品功能与实际应用价值。15111326
角型电感式接近开关
PS17-5D1, PS17-5D2, PS17-5Y1, PS17-5Y2, PS-05N, PS-05N2, PS-05N3, PS-05P, PS-05P2 PS-05P3, PS-05D1, PS-05D2, PS-05Y1, PS-05Y2,PL-05N, PL-05N2, PL-05N3, PL-05P, PL-05P2, PL-05P3, PL-05D1, PL-05D2, PL-05Y1, PL-05Y2,PL-08N, PL-08N2 PL-08N3, PL-08P, PL-08P2, PL-08P3, PL-08D1, PL-08D2, PL-08Y1,PL-08Y2,SN04-N1 SN04-N2,SN04-N3,SN04-P,SN04-P2,SN04-P3,SN04-D1,SN04-D2,SN04-Y1,SN04-Y2,SN05-N1 SN05-N2, SN05-N3, SN05-P, SN05-P2, SN05-P3, SN05-D1, SN05-D2, SN05Y1, SN05-Y2,
SN06-N1, SN06-N2, SN06-N3, SN06-P, SN06-P2, SN06-P3, SN06-D1, SN06-D2, SN06-Y1 SN06-Y2, SN07-N, SN07-N2, SN07-N3, SN07-P, SN07-P2, SN07-P3, SN07-D1, SN07-D2 SN07Y1, SN07-Y2,NI10-Q25-AN6X, NI10-Q25-RN6X, NI10-Q25-RP6X, NI10- Q25-AP6X
NI10-Q25-AD4X, NI10-Q25-RD4X, NI10-Q25-AZ3X, NI10-Q25-RZ3X,NI15-Q30-AN6X NI15-Q30-RN6X, NI15-Q30-RP6X, NI15-Q30-AP6X, NI15-Q30-AD4X, NI15-Q30-RD4X NI15-Q30-AZ3X, NI15-Q30-RZ3X,
接近开关，磁性开关,被广泛应用于各种机械、机床制造业及纺织、造纸、烟草、轻工、食品、化工、矿山、冶金、航空工业、电力保安、汽车工业、船舶交通运输、建筑、地等各行各业，作限位、定位检测，自动计数，测速，自动保护，工业生产自动流水线及微机信号，数控装置等应用.详细技术资料请到公司网站查询 .FJ13-25KA
FJ13 安装方式埋入式非埋入式检测距离 25mm 交流AC90-250V二线制NO 常开 FJ13-M25KA NC 常闭 FJ13-M25KB 三线制NO+NC 常开常闭 FJ13-M25KE 继电输出四线NO+NC 常开常闭 FJ13-M25JC 继电输出五线NO+NC 常开常闭 直流DC6-36VNPNNO 常开 FJ13-M25NA NC 常闭 FJ13-M25NB NO+NC 常开常闭 FJ13-M25NC PNPNO 常开 FJ13-M25PA NC 常闭 FJ13-M25PB NO+NC 常开常闭 FJ13-M25PC 二线制NO 常开 FJ13-M25LA NC 常闭 FJ13-M25LB 输出电压降DC/ACAC 输出电流可控硅SCR 300mA 继电器1A、2A DC三线200mA DC二线 50mA重复精度 消耗电流 响应频率DC 300Hz,AC 10Hz 外壳体材料塑料ABS设定距离0-20mm 标准检测物体60 x 60 x 1（铁）工作环境温度-20℃~+55℃连接方式1.5m PVC电缆防护等级IP67
|
