角型电感式接近开关SN05Y1 厂家
产品概述
角型电感式接近开关SN05Y1是一款采用电磁感应原理设计的高性能传感器，专为工业自动化控制中的金属物体检测而开发。其独特的角型结构便于在狭窄或复杂空间安装，适用于机械定位、流水线计数等场景。该产品通过涡流效应实现非接触式检测，反应速度快且耐用性强，可在多种工业环境中稳定工作。18
技术特点
SN05Y1采用高频振荡器与信号放大电路一体化设计，检测距离精准，重复定位精度高。外壳选用耐腐蚀材质，防护等级达到IP67，可抵御油污、粉尘及潮湿环境影响。输出方式支持NPN/PNP三线制配置，兼容PLC等控制设备。内置LED状态指示灯，便于现场调试与故障排查。产品工作电压覆盖DC6-36V宽范围，适应不同电气环境需求。21421
应用领域
适用于冶金、矿山机械、食品包装、汽车制造等行业，可检测各类金属工件（如铁、铝、铜等）。典型应用包括冲床安全防护、传送带物料监控、旋转设备速度检测等。其紧凑的角型设计特别适合在安装空间受限的场合使用，例如机床导轨侧壁或自动化设备内部模块。51120
产品优势
相较于传统机械开关，SN05Y1无物理接触磨损，使用寿命显著延长。抗电磁干扰能力强，在电机或变频器附近仍能保持稳定信号输出。温度适应性广，可在-25℃至+70℃环境中连续工作。提供插件式和出线式两种接线方式，满足不同现场布线需求。7915
Introduction
The angular inductive proximity switch SN05Y1 is a high-performance sensor based on electromagnetic induction principle, designed for metal object detection in industrial automation. Its angular housing facilitates installation in confined spaces, making it ideal for mechanical positioning and conveyor counting applications. Through eddy current effect, it achieves contactless detection with fast response and enhanced durability, ensuring reliable performance in diverse industrial environments.112
Key Features
Equipped with integrated high-frequency oscillator and signal amplification circuit, SN05Y1 delivers precise detection distance and high repeatability. The corrosion-resistant housing with IP67 protection resists oil, dust, and moisture. Compatible with NPN/PNP three-wire configurations, it seamlessly connects to PLC systems. Built-in LED status indicator simplifies on-site commissioning and troubleshooting. Wide operating voltage range (DC6-36V) adapts to various power conditions.21626
Applications
Widely used in metallurgy, mining machinery, packaging, and automotive manufacturing, SN05Y1 detects diverse metals (iron, aluminum, copper, etc.). Typical scenarios include punch press safety guarding, conveyor material monitoring, and rotary equipment speed measurement. The compact angular design is particularly suitable for space-constrained installations like machine tool rails or internal modules of automated equipment.52225
Benefits
Compared with mechanical switches, SN05Y1 eliminates physical wear through contactless operation, significantly extending service life. With strong EMI resistance, it maintains stable signal output near motors or frequency converters. Broad temperature tolerance (-25℃ to +70℃) ensures continuous operation in harsh conditions. Both connector and cable variants are available for flexible wiring solutions.71829
角型电感式接近开关
PS17-5D1, PS17-5D2, PS17-5Y1, PS17-5Y2, PS-05N, PS-05N2, PS-05N3, PS-05P, PS-05P2 PS-05P3, PS-05D1, PS-05D2, PS-05Y1, PS-05Y2,PL-05N, PL-05N2, PL-05N3, PL-05P, PL-05P2, PL-05P3, PL-05D1, PL-05D2, PL-05Y1, PL-05Y2,PL-08N, PL-08N2 PL-08N3, PL-08P, PL-08P2, PL-08P3, PL-08D1, PL-08D2, PL-08Y1,PL-08Y2,SN04-N1 SN04-N2,SN04-N3,SN04-P,SN04-P2,SN04-P3,SN04-D1,SN04-D2,SN04-Y1,SN04-Y2,SN05-N1 SN05-N2, SN05-N3, SN05-P, SN05-P2, SN05-P3, SN05-D1, SN05-D2, SN05Y1, SN05-Y2,
SN06-N1, SN06-N2, SN06-N3, SN06-P, SN06-P2, SN06-P3, SN06-D1, SN06-D2, SN06-Y1 SN06-Y2, SN07-N, SN07-N2, SN07-N3, SN07-P, SN07-P2, SN07-P3, SN07-D1, SN07-D2 SN07Y1, SN07-Y2,NI10-Q25-AN6X, NI10-Q25-RN6X, NI10-Q25-RP6X, NI10- Q25-AP6X
NI10-Q25-AD4X, NI10-Q25-RD4X, NI10-Q25-AZ3X, NI10-Q25-RZ3X,NI15-Q30-AN6X NI15-Q30-RN6X, NI15-Q30-RP6X, NI15-Q30-AP6X, NI15-Q30-AD4X, NI15-Q30-RD4X NI15-Q30-AZ3X, NI15-Q30-RZ3X,
接近开关，磁性开关,被广泛应用于各种机械、机床制造业及纺织、造纸、烟草、轻工、食品、化工、矿山、冶金、航空工业、电力保安、汽车工业、船舶交通运输、建筑、地等各行各业，作限位、定位检测，自动计数，测速，自动保护，工业生产自动流水线及微机信号，数控装置等应用.详细技术资料请到公司网站查询 .FJ13-25KA
FJ13 安装方式埋入式非埋入式检测距离 25mm 交流AC90-250V二线制NO 常开 FJ13-M25KA NC 常闭 FJ13-M25KB 三线制NO+NC 常开常闭 FJ13-M25KE 继电输出四线NO+NC 常开常闭 FJ13-M25JC 继电输出五线NO+NC 常开常闭 直流DC6-36VNPNNO 常开 FJ13-M25NA NC 常闭 FJ13-M25NB NO+NC 常开常闭 FJ13-M25NC PNPNO 常开 FJ13-M25PA NC 常闭 FJ13-M25PB NO+NC 常开常闭 FJ13-M25PC 二线制NO 常开 FJ13-M25LA NC 常闭 FJ13-M25LB 输出电压降DC/ACAC 输出电流可控硅SCR 300mA 继电器1A、2A DC三线200mA DC二线 50mA重复精度 消耗电流 响应频率DC 300Hz,AC 10Hz 外壳体材料塑料ABS设定距离0-20mm 标准检测物体60 x 60 x 1（铁）工作环境温度-20℃~+55℃连接方式1.5m PVC电缆防护等级IP67
|
