角型电感式接近开关SN06-P2 价格
产品概述
角型电感式接近开关SN06-P2是一款高性能非接触式检测设备，采用电磁感应原理设计，专为工业自动化场景中金属物体的精准检测而开发。其紧凑的方形外壳结构（18×18×35mm）适合狭小空间安装，背面配备LED工作状态指示灯，当检测到金属物体时红色LED亮起，操作直观便捷。该产品通过LC高频振荡器产生交变磁场，当金属目标进入感应区域时会引发涡流效应，从而触发开关信号输出，实现无接触、无磨损的可靠检测。188
核心特点
SN06-P2采用NPN晶体管集电极开路输出模式，黑线作为信号输出端可在检测到物体时下拉至地电平，支持12-24V宽电压输入，驱动能力达100mA，可直接控制继电器等负载。产品具有响应速度快（500Hz）、抗干扰能力强、防护等级达IP67等特点，能在油污、粉尘等恶劣工业环境中稳定工作。其检测距离为1mm±10%，标准检测体为铁质材料，工作温度范围覆盖-25℃至+85℃。独特的非接触式设计避免了机械磨损，使得产品寿命远超传统机械开关。1723
技术参数
• 电气特性：直流三线制，工作电压6-36VDC，输出电流≤200mA
• 物理规格：角型外壳尺寸18×18×35mm，引线长度标准100mm（可定制）
• 环境适应性：环氧树脂全密封结构，耐油污、抗震动，适应高频机械动作场合
• 检测性能：铁质金属标准检测距离1mm±10%，响应时间≤1ms
• 输出配置：NPN常开/常闭可选（SN06-P2为常开型），集电极开路输出
产品采用耐冲击ABS材质外壳，通过优化磁场分布设计实现稳定检测性能，对不锈钢、铜、铝等常见金属均有良好响应。内置反向极性保护和短路保护电路，确保设备安全运行。913
应用场景
SN06-P2广泛应用于机床刀具定位、自动化生产线物料计数、机械手臂末端位置检测等场景。在汽车制造领域用于零部件装配到位检测，在包装机械中实现金属包装盒的通过检测，在电梯控制系统里进行平层定位。其紧凑设计特别适合空间受限的安装环境，如微型齿轮箱的转速监测、AGV小车防撞检测等。产品兼容PLC、单片机等控制系统，可通过外接1K电阻轻松转换为电压信号输出模式。610
Product Introduction
The angular inductive proximity switch SN06-P2 is a high-performance non-contact detection device utilizing electromagnetic induction principle, specifically designed for precise metal object detection in industrial automation scenarios. Its compact rectangular housing (18×18×35mm) fits confined spaces, with a built-in LED status indicator that illuminates red when metal targets are detected, providing intuitive operation feedback. The LC oscillator generates alternating magnetic fields to induce eddy currents in metal objects, triggering reliable contactless switching without mechanical wear. 188
Key Features
Featuring NPN open-collector output configuration, the black wire serves as signal output that pulls to ground level upon detection, supporting 12-24V wide voltage range with 100mA drive capacity for direct relay control. With 500Hz response frequency, IP67 protection rating and anti-interference design, it operates stably in harsh environments containing oil, dust or vibrations. The 1mm±10% sensing distance (for iron) and -25℃ to +85℃ temperature range ensure reliable performance. Non-contact mechanism eliminates physical wear for extended service life. 1723
Specifications
• Electrical: 3-wire DC, 6-36VDC operating voltage, ≤200mA output current
• Mechanical: 18×18×35mm angular housing, standard 100mm cable (customizable)
• Environment: Epoxy encapsulated, resistant to oil and vibration for high-frequency operations
• Sensing: 1mm±10% detection for iron, ≤1ms response time
• Output: NPN NO/NC selectable (SN06-P2 default NO), open-collector output
The ABS housing with optimized magnetic field design ensures consistent detection of stainless steel, copper and aluminum. Integrated reverse polarity and short-circuit protection enhance operational safety. 913
Applications
Ideal for machine tool positioning, production line counting, and robotic arm end-effector detection. Used in automotive assembly for component presence verification, packaging machinery for metal container passage detection, and elevator control systems for leveling. Compact size suits space-constrained installations like micro gearbox speed monitoring and AGV collision avoidance. Compatible with PLCs and microcontrollers, easily converts to voltage signal output via external 1K resistor. 610
角型电感式接近开关
PS17-5D1, PS17-5D2, PS17-5Y1, PS17-5Y2, PS-05N, PS-05N2, PS-05N3, PS-05P, PS-05P2 PS-05P3, PS-05D1, PS-05D2, PS-05Y1, PS-05Y2,PL-05N, PL-05N2, PL-05N3, PL-05P, PL-05P2, PL-05P3, PL-05D1, PL-05D2, PL-05Y1, PL-05Y2,PL-08N, PL-08N2 PL-08N3, PL-08P, PL-08P2, PL-08P3, PL-08D1, PL-08D2, PL-08Y1,PL-08Y2,SN04-N1 SN04-N2,SN04-N3,SN04-P,SN04-P2,SN04-P3,SN04-D1,SN04-D2,SN04-Y1,SN04-Y2,SN05-N1 SN05-N2, SN05-N3, SN05-P, SN05-P2, SN05-P3, SN05-D1, SN05-D2, SN05Y1, SN05-Y2,
SN06-N1, SN06-N2, SN06-N3, SN06-P, SN06-P2, SN06-P3, SN06-D1, SN06-D2, SN06-Y1 SN06-Y2, SN07-N, SN07-N2, SN07-N3, SN07-P, SN07-P2, SN07-P3, SN07-D1, SN07-D2 SN07Y1, SN07-Y2,NI10-Q25-AN6X, NI10-Q25-RN6X, NI10-Q25-RP6X, NI10- Q25-AP6X
NI10-Q25-AD4X, NI10-Q25-RD4X, NI10-Q25-AZ3X, NI10-Q25-RZ3X,NI15-Q30-AN6X NI15-Q30-RN6X, NI15-Q30-RP6X, NI15-Q30-AP6X, NI15-Q30-AD4X, NI15-Q30-RD4X NI15-Q30-AZ3X, NI15-Q30-RZ3X,
接近开关，磁性开关,被广泛应用于各种机械、机床制造业及纺织、造纸、烟草、轻工、食品、化工、矿山、冶金、航空工业、电力保安、汽车工业、船舶交通运输、建筑、地等各行各业，作限位、定位检测，自动计数，测速，自动保护，工业生产自动流水线及微机信号，数控装置等应用.详细技术资料请到公司网站查询 .FJ13-25KA
FJ13 安装方式埋入式非埋入式检测距离 25mm 交流AC90-250V二线制NO 常开 FJ13-M25KA NC 常闭 FJ13-M25KB 三线制NO+NC 常开常闭 FJ13-M25KE 继电输出四线NO+NC 常开常闭 FJ13-M25JC 继电输出五线NO+NC 常开常闭 直流DC6-36VNPNNO 常开 FJ13-M25NA NC 常闭 FJ13-M25NB NO+NC 常开常闭 FJ13-M25NC PNPNO 常开 FJ13-M25PA NC 常闭 FJ13-M25PB NO+NC 常开常闭 FJ13-M25PC 二线制NO 常开 FJ13-M25LA NC 常闭 FJ13-M25LB 输出电压降DC/ACAC 输出电流可控硅SCR 300mA 继电器1A、2A DC三线200mA DC二线 50mA重复精度 消耗电流 响应频率DC 300Hz,AC 10Hz 外壳体材料塑料ABS设定距离0-20mm 标准检测物体60 x 60 x 1（铁）工作环境温度-20℃~+55℃连接方式1.5m PVC电缆防护等级IP67
|
