角型电感式接近开关NI15-Q30-RZ3X 供应
产品介绍
中文介绍
角型电感式接近开关 NI15-Q30-RZ3X 是一款高性能的自动化检测设备，广泛应用于工业自动化领域。该产品采用先进的电感检测技术，能够实现非接触式检测，具有高精度、高可靠性和长寿命的特点。其检测距离为 15mm ± 10%，设定距离范围为 0~13mm，能够有效检测磁性金属物体。该开关适用于交流电源，电压范围为 AC110-220V（36-250V），50/60Hz，具备良好的电源适应性。此外，NI15-Q30-RZ3X 还具备电源反接保护和短路保护功能，可直接与 PLC 等自动化控制系统连接，操作简便，经济实用。其外壳采用坚固耐用的材料，防护等级高，能够适应复杂的工业环境。
English Introduction
The NI15-Q30-RZ3X is a high-performance inductive proximity switch designed for industrial automation applications. Utilizing advanced inductive sensing technology, it offers non-contact detection with high precision, reliability, and durability. The switch has a detection distance of 15mm ± 10% and an adjustable sensing range of 0~13mm, making it suitable for detecting ferromagnetic metal objects. It operates on an AC power supply with a voltage range of AC110-220V (36-250V) at 50/60Hz, providing excellent power adaptability. The NI15-Q30-RZ3X also features reverse polarity protection and short-circuit protection, allowing it to be directly connected to PLCs and other automation control systems for easy and cost-effective operation. Its robust casing and high protection rating make it suitable for harsh industrial environments.
角型电感式接近开关
PS17-5D1, PS17-5D2, PS17-5Y1, PS17-5Y2, PS-05N, PS-05N2, PS-05N3, PS-05P, PS-05P2 PS-05P3, PS-05D1, PS-05D2, PS-05Y1, PS-05Y2,PL-05N, PL-05N2, PL-05N3, PL-05P, PL-05P2, PL-05P3, PL-05D1, PL-05D2, PL-05Y1, PL-05Y2,PL-08N, PL-08N2 PL-08N3, PL-08P, PL-08P2, PL-08P3, PL-08D1, PL-08D2, PL-08Y1,PL-08Y2,SN04-N1 SN04-N2,SN04-N3,SN04-P,SN04-P2,SN04-P3,SN04-D1,SN04-D2,SN04-Y1,SN04-Y2,SN05-N1 SN05-N2, SN05-N3, SN05-P, SN05-P2, SN05-P3, SN05-D1, SN05-D2, SN05Y1, SN05-Y2,
SN06-N1, SN06-N2, SN06-N3, SN06-P, SN06-P2, SN06-P3, SN06-D1, SN06-D2, SN06-Y1 SN06-Y2, SN07-N, SN07-N2, SN07-N3, SN07-P, SN07-P2, SN07-P3, SN07-D1, SN07-D2 SN07Y1, SN07-Y2,NI10-Q25-AN6X, NI10-Q25-RN6X, NI10-Q25-RP6X, NI10- Q25-AP6X
NI10-Q25-AD4X, NI10-Q25-RD4X, NI10-Q25-AZ3X, NI10-Q25-RZ3X,NI15-Q30-AN6X NI15-Q30-RN6X, NI15-Q30-RP6X, NI15-Q30-AP6X, NI15-Q30-AD4X, NI15-Q30-RD4X NI15-Q30-AZ3X, NI15-Q30-RZ3X,
接近开关，磁性开关,被广泛应用于各种机械、机床制造业及纺织、造纸、烟草、轻工、食品、化工、矿山、冶金、航空工业、电力保安、汽车工业、船舶交通运输、建筑、地等各行各业，作限位、定位检测，自动计数，测速，自动保护，工业生产自动流水线及微机信号，数控装置等应用.详细技术资料请到公司网站查询 .FJ13-25KA
FJ13 安装方式埋入式非埋入式检测距离 25mm 交流AC90-250V二线制NO 常开 FJ13-M25KA NC 常闭 FJ13-M25KB 三线制NO+NC 常开常闭 FJ13-M25KE 继电输出四线NO+NC 常开常闭 FJ13-M25JC 继电输出五线NO+NC 常开常闭 直流DC6-36VNPNNO 常开 FJ13-M25NA NC 常闭 FJ13-M25NB NO+NC 常开常闭 FJ13-M25NC PNPNO 常开 FJ13-M25PA NC 常闭 FJ13-M25PB NO+NC 常开常闭 FJ13-M25PC 二线制NO 常开 FJ13-M25LA NC 常闭 FJ13-M25LB 输出电压降DC/ACAC 输出电流可控硅SCR 300mA 继电器1A、2A DC三线200mA DC二线 50mA重复精度 消耗电流 响应频率DC 300Hz,AC 10Hz 外壳体材料塑料ABS设定距离0-20mm 标准检测物体60 x 60 x 1（铁）工作环境温度-20℃~+55℃连接方式1.5m PVC电缆防护等级IP67
|
