铠装铂电阻WZPK-324S 厂家
产品概述
铠装铂电阻WZPK-324S是一种高精度温度传感器，采用先进的设计理念和制造工艺，具有优异的性能和可靠性。该产品广泛应用于工业过程控制、环境监测、科学实验等领域，能够精确测量-200℃至500℃范围内的温度变化。相比传统装配式铂电阻，WZPK-324S体积更小、柔韧性更好，可轻松安装于空间受限或需要快速响应的场合。其独特的结构设计使其具备出色的抗震性能和机械强度，适合在各种复杂工况下稳定工作。314
产品特点
WZPK-324S铠装铂电阻采用不锈钢外保护管和高密度氧化绝缘材料内芯结构，既保证了良好的抗污染性能，又确保了产品的耐用性。该产品响应速度快，能够快速捕捉温度变化，减小动态误差；测量精度高，可提供准确可靠的温度数据。产品采用模块化设计，直径从φ3mm到φ6mm可选，长度可根据客户需求定制，适应不同安装环境的要求。此外，该产品的可弯曲特性使其能够适应复杂管道的安装需求，为特殊场合的温度测量提供了便利的解决方案。17
技术优势
WZPK-324S采用优质进口薄膜电阻元件，确保了温度测量的稳定性和一致性。产品具有热惰性小、反应迅速的特点，相比普通铂电阻能更快地反映温度变化。其独特的铠装结构提供了优异的耐振动和抗冲击性能，延长了产品使用寿命。该产品支持多种安装方式，包括固定卡套螺纹、可动卡套螺纹等，方便用户选择最适合的安装方案。同时，产品可直接通过铜导线与二次仪表连接使用，简化了系统集成过程。1021
应用领域
WZPK-324S铠装铂电阻适用于环保、食品加工、化工、石油、电气等多个行业的温度测量需求。在污水处理系统、食品生产线、化工反应釜、石油储罐等场合都有成功应用案例。产品良好的电输出特性使其能够与各类显示仪表、记录仪、调节器、数据记录仪及计算机系统兼容，为工业自动化控制提供精确的温度输入信号。在恶劣环境条件下，该产品仍能保持稳定的工作性能，是工业温度测量的理想选择。215
Product Introduction
The WZPK-324S armored platinum resistance thermometer is a precision temperature sensor designed for industrial applications. With a compact and flexible structure, it outperforms conventional assembled platinum resistors in installation flexibility and response speed. The product features a stainless steel protective sheath filled with high-density oxide insulation material, ensuring excellent resistance to contamination and mechanical durability. Its small diameter and customizable length make it suitable for various installation scenarios, including confined spaces and complex piping systems.13
Key Features
The WZPK-324S stands out with its fast thermal response, significantly reducing dynamic measurement errors. The imported thin-film resistive element guarantees measurement accuracy and long-term stability. The armored construction provides superior vibration resistance and impact protection compared to standard platinum resistance thermometers. Available in multiple diameters (from φ3mm to φ6mm), the product supports different installation methods like fixed sleeve threads and movable sleeve threads, offering flexibility for diverse application requirements. Its bendable nature allows easy installation in challenging locations.714
Technical Advantages
This temperature sensor demonstrates outstanding performance in harsh environments, maintaining measurement stability under various industrial conditions. The optimized design ensures minimal thermal inertia for quick response to temperature changes. The product s robust construction enhances its service life while maintaining precise temperature readings. Compatible with standard copper connecting wires, it can be directly integrated with most secondary instruments and control systems. The WZPK-324S provides reliable temperature data for process control and monitoring systems across different industries.1021
Application Scenarios
The WZPK-324S finds wide applications in environmental protection, food processing, chemical engineering, petroleum, and electrical industries. It performs exceptionally well in monitoring temperatures in wastewater treatment systems, food production lines, chemical reactors, and oil storage tanks. The product s stable electrical output characteristics allow seamless connection with various display instruments, recorders, regulators, and computer systems. Its ability to maintain performance under demanding conditions makes it a preferred choice for industrial temperature measurement tasks requiring both accuracy and reliability.215
铠装铂电阻
WZPK-563U，WZPK-564U，WZPK-565U，WZPK-566U，WZPK-173U，WZPK-174U，WZPK-175U，WZPK-176U，WZPK-273U，WZPK-274U，WZPK-275U，WZPK-276U，WZPK-373U，WZPK-374U，WZPK-375U，WZPK-376U，WZPK-473U，WZPK-474U，WZPK-475U，WZPK-476U，WZPK-573U，WZPK-574U，WZPK-575U，WZPK-576U，WZPK-103S，WZPK-104S，WZPK-105S，WZPK-106S，WZPK2-105SA，WZPK2-106SA，WZPK-203S，WZPK-204S，WZPK-205S，WZPK-206S，WZPK2-205SA，WZPK2-206SA，WZPK-303S，铠装铂电阻，WZPK-535S，WZPK-533S，WZPK-534S，WZPK2-436SA，WZPK2-435SA，WZPK-435S，WZPK-434S，WZPK-433S，WZPK2-336SA，WZPK-235U，WZPK-134U，WZPK-236S，WZPK2-335SA，WZPK-336S，WZPK-235S，WZPK-325U，WZPK-234S，WZPK-335S，WZPK-404U，WZPK-126U，WZPK-334S，WZPK-233S，WZPK-365U，WZPK2-136SA，WZPK-333S，WZPK2-236SA，WZPK2-135SA，WZPK-136S，WZPK2-235SA，WZPK-135S，WZPK-134S，WZPK-524U，WZPK-123U，WZPK2-525SA，WZPK-525S，WZPK-524S，WZPK-523S，WZPK2-425SA，WZPK-425S，WZPK-424S，WZP2-44SAB，WZPK-423S，WZPK-326S，WZPK2-325SA，WZPK-325S，WZPK-323S，WZPK-324S，WZPK2-226SA，WZPK2-225SA，WZPK-226S，WZPK-225S，WZPK-223S，WZPK2-126SA，WZPK2-125SA，WZPK-125S，WZPK-126S，WZPK-124S，WZPK-123S，WZPK2-506SA，WZPK2-505SA，WZP2-420D，
概述
铠装铂电阻是一种温度传感器，它比装配式铂电阻直径小，易弯曲，抗震性好，适宜安装在装配式铂电阻无法安装的场合。本公司生产的WZPK系列铠装铂电阻采用引进铂电阻测温元件，因此，具有精确、灵敏、热响应时间快、质量稳定、使用寿命长等特点。
特点
★ 热响应时间短，减小动态误差
★ 直径小，长度不受限制
★ 测量精确度高
★ 进口薄膜电阻元件，性能可靠稳定
工作原理
铠装铂电阻是利用物质在温度变化时，其电阻值也随着发生变化的特征来测量温度的，当阻值变
化时，工作仪表便显示出阻值所对应的温度值。
|
