YK-34UV超声波测厚仪产品介绍

（中文版）

YK-34UV是一款专业级便携式超声波测厚仪，采用高频脉冲反射原理设计，适用于金属、塑料、陶瓷等多种均质材料的厚度测量。本设备通过非破坏性检测方式，帮助用户快速获取材料厚度数据，适用于工业制造、设备维护、质量检测等场景。

技术特点：

1. 宽量程覆盖能力：支持0.8mm至300mm的测量范围（具体数值因材料声速而异），满足常见工业材料的检测需求。针对特殊薄壁材料优化信号处理算法，提升超薄件测量稳定性。
2. 双模式探头系统：标配分体式双晶探头（5MHz）和单晶探头（10MHz），可根据不同工况灵活切换。探头线缆采用抗弯折设计，延长使用寿命。
3. 智能温度补偿功能：内置环境温度传感器，自动修正温度对声速的影响，提升低温/高温工况下的测量准确性。
4. 可视化交互界面：配备2.8英寸IPS液晶屏，支持波形显示和测量值双重呈现。直观的菜单导航系统配合三向摇杆控制，简化操作流程。
5. 数据管理模块：内置512组存储单元，支持按项目编号分类存储。可通过USB接口导出CSV格式数据，兼容主流分析软件。

应用领域：
适用于石化管道壁厚监测、机械部件磨损评估、压力容器定期检验等领域。在航空航天复合材料检测、船舶制造过程控制等场景中，其穿透涂层测量功能可有效提升检测效率。设备符合IP65防护等级，在潮湿、多尘的工业环境中仍能保持可靠性能。

人性化设计：
人体工程学外壳采用防滑橡胶包裹，整机重量控制在290g（含电池）。两节AA电池供电可支持连续工作30小时，设有低电量预警提示。随机配置便携保护箱、标准试块及清洁套装。

（English Version）

The YK-34UV Ultrasonic Thickness Gauge is a professional-grade portable measurement device utilizing pulse-echo principle for accurate thickness assessment of metallic, plastic, and ceramic materials. This non-destructive testing instrument provides efficient thickness data acquisition for industrial maintenance, manufacturing quality control, and equipment inspection applications.

Technical Highlights:

1. Extended measurement range covers 0.8mm to 300mm (varies by material sound velocity), with enhanced signal processing algorithms for ultra-thin material detection.
2. Dual-mode probe system includes standard 5MHz dual-element probe and 10MHz single-element probe, featuring reinforced cable design for improved durability.
3. Automatic temperature compensation adjusts measurement results based on ambient temperature variations, ensuring accuracy across -10℃ to 50℃ operating range.
4. Interactive interface combines 2.8" IPS LCD display with waveform visualization and three-axis joystick control, enabling intuitive operation.
5. Data management system stores 512 measurement records with project indexing, supporting CSV export via USB for third-party analysis.

Application Scenarios:
Ideal for pipeline corrosion monitoring, mechanical component wear analysis, and pressure vessel inspection. The coating-penetration measurement function proves valuable in aerospace composite material testing and shipbuilding quality assurance. IP65-rated housing ensures reliable performance in challenging industrial environments.

User-Centric Design:
Ergonomic casing with non-slip rubber coating weighs 290g (including batteries). Powered by two AA batteries delivering 30-hour continuous operation with low-power alert. Package includes carrying case, calibration test blocks, and maintenance accessories.
